9 DIGITAL QUAD / SPLIT SCREEN MONITOR BUILT-IN DVR RECORDING. 9 TFT LCD QUAD / SPLIT SCREEN. + 4 x CCD SIDE VIEW CAMERAS. Since the advent of the motor vehicle, drivers have always been in search of a way to see behind the ride, in the area which mirrors alone cannot reach, also called the Blind Zone. Now the backup camera system has become a secure, affordable way of eliminating the blind zone while significantly increasing rear view safety. By providing the user with a real-time, crystal clear view from the back of any vehicle, a rear view back up camera allows you to reverse with confidence! The backup camera systems that will fit virtually any truck or trailer, emergency vehicle or commercial vehicle, including school buses, house boats, coach buses, motor homes and RV. Rear view cameras make parking, driving and backing up a safer experience for everyone. Built-in DVR Quad / Split Screen Digital Monitor System. * Quad Monitor Camera System is Able to Show 4 Camera Views at one Time. IR LED Night Vision Waterproof Camera. 4 pin Connector Color CCD Sensor. / Mirror Image adjustable. On menu of DVR. PART 1 : 9 TFT LCD QUAD / SPLIT SCREEN MONITOR. The recording file stored in SD card, maximum 64G. When play the videotape, 15 minutes is a segment(you can set up the time), each camera has a separate video file. The unit can re record on the same card in a loop. This unit can support one camera with audio, so the driver can hear instructions immediately from the person guiding him at the rear of the RV. Appearance and Keystroke function. We can set the image mode through three Keystroke: #2, #6, #7 and #8. Press the “AV(#2)” button over and over again, monitor will show single video, dual video, triple video, quad video in turn. We must use this remote control to set all DVR function. AV1/AV2/AV3/AV4 with trigger wire, once trigger wire activated, i mage automatically switchover to corresponding camera, and take picture soon. The power cable has 7 wires, their definition as follows: Red and yellow wire: 12-32V Black wire: GND Green wire(remark 1): trigger wire, control V1 Purple wire(remark 2): trigger wire, control V2 Gray wire(remark 3): trigger wire, control V3 White wire(remark 4): trigger wire, control V4. Please kindly note: please take the red wire and yellow wire together, and then connect them to the 1232 volt. About the bracket of monitor. The monitor has U-Braccket and Metal Bracket. Please kindly note: We will. Send U-Bracket as default. If need Metal Bracket, please send a message to us or write it in the comment when you order. PART 2 : SIDE VIEW CAMERA. DC12V Power Supply (from Monitor). Without additional external power supply. Wateproof & Shockproof Color CCD Camera. It has 10 LEDs for good clear night vision. We also provide the white side camera. As default, please cut the. If need NON- Mirror Image. Image Type: High Performance Color 1/3 CCD. Horizontal Resolution: 600TV Lines. Usable Illumination : 0Lux (Built in 9pcs IR LED’s for Picture Support in the Dark). Free viewing angle: 120 degree. This side view camera not only can use for side view, but also can use for rear view and front view. PART 3 : 15m(49ft) 4-Pin SHIELD CABLE. No another power cable is needed to connect cameras. It will shield vehicle’s circuit interference better than normal AV cable. Optional Extra 5m(16ft), 10m(32ft), 15m(49ft) or 20m(65ft). Shield Cable as default, please leave us a message for special need. The backup camera systems that will fit virtually any truck or trailer, emergency vehicle or commercial vehicle, including school buses, house boats, coach buses, Fork-lifts, motor homes and RVs! How to Configure Your System. NOTE 1: About this Monitor. (1) This monitor has two type brackets, one is U-bracket, the other is metal bracket, we send U-bracket as default, the metal bracket is requestion. (2) We also can provide monitor with speaker, It can be connect one audio camera. NOTE 2: About the Extend 4pin Cable. This system included 15(49ft) cables, which is connect the monitor to the cameras. Please confirm the length of your vehicle. We can provide 4PIN cables in 5m(16ft), 10m(32ft) or 20m(65ft) lengths. NOTE 3: About the Backup Camera. (2) We send black shell camera as default, we also provide white shell camera. NOTE 4: About the Side Camera. We send black shell camera as default, we also provide white shell camera. PART 5: PACKAGE INCLUDES. (1) Side View Camera x 4. (2) 9 inch TFT-LCD DVR Monitor x 1. SD Card Is Not Included In The Pack. International Buyers – Please Note. We offer Rear View Back up Camera System, Reversing Camera System, TFT LCD Monitor, Auto Shutter Camera and CCTV Camera for Car, Heavy Truck, Trailer, SUV, Farm Tractor, Forklift, Compactor Vehicle, Street Sweeper, Mobile Home, Passenger Bus and Mining Vehicle. We choose the best materials from USA, Korea and Japan, because we need high quality material to ensure the stability of our products. Our products have been waterproof test, aging test, high and low temperature test and swing test. We use all-glass lens, glass lens elements from the 4-6; other factories products, most are a combination of plastic with glass lenses; Glass lens imaging effect. When your used at high or low temperatures, plastic lens will deform, the image becomes blurred. But glass lens will not. So we can help our clients to solve any fault in use. We passed following six basic experimental projects. Resistance to vibration test and technical graphs. Project & test conditions. Confirmation of the project. After the test, it should meet the general performance requirements, appearance should not have the Defect to affect the actual action and the energized image function is normal. Humidification and caloric test & graphs. Set the temperature is 70. And time is 2 hours as a circle. In the non-energized state to operate 60 circles. Then after 60 circles, put the camera in the condition of -10. To operate for 120H, each 24H verify related functionality. After the test, all the functions of the camera should meet the requirements of general performance. There should be no defect on the appearance to affect the actual action or any blur (condensation) phenomena. Continuous high temperature operation test and technical graphs. Place the camera under a humidified ambient temperature of +85. For one hour, then energized it for 96 hours. External power supply voltage of 12V DC. Function can be confirmed after energizing for 96 hours. When back to room temperature, it should meet the general requirements of performance and there should be no defect on the appearance to affect the actual action. Low Temprature continuous operation test& diagram of curves. Put the camera at the environment of absence of humidity and the temperature is around -40. For an hour, then energized it for 96 hours. External power supply voltage is 12V DC. After energized for 96 hours to confirm the function. Back to the room temperature, all the functions should meet the requirements of general performance. Appearance should not have the defect to affect the actual action. Momentary power cut test and additional electrostatic test chart. External power supply voltage 12V DC at standard temperature condition, momentary power cut for 10msec. Setting one circle of power supply and momentary power cut for 3 sec, and testing 10 times. After 10 circles tests, according to the quality reliability, there will be no obvious differences of the image texture. After the test, all the functions should meet the requirements of general performance. Additional electrostatic test chart. When the power supply voltage is. 1kV, all the functions of the camera should meet the requirements of general performance. 2kV, all the functions of the camera should meet the requirements of general performance after the test. 5kV, there should no damage for the camera. Waterproof test & Diagram of curves. Put one meter deep water into a container, the place 3 cameras at 1.0m, 0.8m, 0.5m three positions for 60 minutes then take them out of the water. After the test, the inner box should not have water and the lens face shall not be fuzzy. We will replace items which are malfunctioning items for 30 days from the date you receive them. We strive to answer all messages as quickly as possible. Thank you in advance for your patience. Is our life, before you leave a. We care our valued customers, and will always help you. Please give us the opportunity to resolve a problem, we understood the concerns and frustrations you might have, and will try our best to resolve the issues. All communications are handled through emails. Thanks for your business! This item is in the category “Consumer Electronics\Vehicle Electronics & GPS\Car Video\Rear View Monitors/Cams & Kits”. The seller is “anxa086″ and is located in this country: CN. This item can be shipped to United States.
- Camera Connection Type: Wired
- Model: A105
- Country/Region of Manufacture: China
- Screen Display: TFT – LCD
- Type: Rear View Camera Kit
- Brand: anxa-auto
- Screen Size: 9\
